Trimble 90030 Small Rear Dozer/Grader Main Harness – GCS900
The Trimble 90030 Small Rear Dozer/Grader Main Harness is a rear wiring harness designed for Trimble GCS900 Grade Control Systems installed on compatible dozers and motor graders.
Part number 90030 is identified as the Small Rear Dozer/Grader Harness and forms part of the main GCS900 wiring system. The rear harness provides connections between the front harness and key machine-control components, including the data radio, GPS receivers, control box, remote switches, lightbar, power system, and valve modules, depending on the machine configuration.
Product Details
Manufacturer: Trimble
Part Number: 90030
Product Type: Rear Main Harness / Wiring Harness
Description: Small Rear Dozer/Grader Harness
System: Trimble GCS900
Application: Dozer and motor grader machine control systems
Function: Connects multiple GCS900 system components within the machine
Application Type: Grade control / machine control
Related Part: 90010 – Large Rear Dozer/Grader Harness
Application
The Trimble 90030 Rear Harness is used in compatible GCS900 dozer and motor grader installations.
Trimble GCS900 installation documentation identifies the rear harness as the connection between the front harness and components such as the data radio, GPS receivers, CB4x0 control box, remote switches, lightbars, power module/power cable, and VM430 valve modules. For motor grader installations, the rear harness connects the front harness with the cab harness, data radio, power module and valve module.
The 90030 is specifically listed as the Small Rear Dozer/Grader Harness, while 90010 is the corresponding large rear harness.
Condition: New
Shipping: Fast worldwide shipping available
Seller: UAB "Aivenos statybinė technika"
Contact us today via Phone, WhatsApp, or Viber
+370 675 75 756
