Yanmar AEM02012 Fuel Line – Flexible Nonmetallic Tubing
The AEM02012 is a flexible nonmetallic tubing used in fuel-system applications on selected Yanmar-powered generator sets. The tubing is manufactured from flexible polyurethane and is suitable for fuel-line and fluid-routing applications where resistance to pressure, temperature, and abrasion is required.
The part is cross-referenced to NSN 4720-01-464-0411 and Yanmar / military generator part number 95-8030-27.
Product Details:
Part Number: AEM02012
Related Part Number: 95-8030-27
Description: Flexible Nonmetallic Tubing / Fuel Line
Manufacturer: Saint-Gobain Performance Plastics
Type: Flexible Polyurethane Tubing
NSN: 4720-01-464-0411
Application: Fuel system / fluid routing
Function: Flexible connection for fuel and fluid lines
Technical Features:
Flexible polyurethane construction
Inside Diameter: 0.188 in (approx. 4.78 mm)
Outside Diameter: 0.312 in (approx. 7.92 mm)
Wall Thickness: 0.062 in (approx. 1.57 mm)
Maximum Working Pressure: 56 psi
Burst Pressure: 280 psi
Temperature Range: approximately -100°F to +200°F
Clear tubing
Minimum bend radius: 0.625 in
Cross References:
AEM02012 – Manufacturer part number
95-8030-27 – Flexible tubing reference
NSN 4720-01-464-0411 – Nonmetallic tubing
4720-01-464-0411 – National Stock Number
Condition: New
Shipping: Fast worldwide shipping available
