JLG 3422137 is a genuine JLG attachment pin designed for compatible JLG rough-terrain scissor lift chassis and axle assemblies. The part is identified as “Pin, 1.00 X 3.75 1045” and is listed by JLG as “Pin, Attach (Bottom)” in the oscillating axle installation.
This heavy-duty steel pin is used as a lower attachment point in the axle/chassis assembly and is designed to provide secure mechanical connection between compatible structural components.
Product Details
Manufacturer: JLG
Part Number: 3422137
Product Type: Attachment Pin / Chassis Pin
Description: Pin, 1.00 X 3.75 1045
JLG Description: Pin, Attach (Bottom)
Diameter: 1.00 in
Length: 3.75 in
Material Specification: 1045 steel
Application: JLG chassis and axle assemblies
Position: Bottom attachment
Application
The JLG 3422137 attachment pin is used in the oscillating axle installation of compatible JLG rough-terrain scissor lifts.
JLG parts manuals identify 3422137 as “Pin, Attach (Bottom)”, with a quantity of two in the relevant axle assembly. It is listed together with the axle weldment, bronze bushings, axle lockout cylinder and other chassis components.
The part is documented in JLG models including:
JLG 25RTS
JLG 33RTS
JLG 40RTS
JLG 400RTS
JLG 500RTS
Condition: New
Shipping: Fast worldwide shipping available
Seller: UAB "Aivenos statybinė technika"
Contact us today via Phone, WhatsApp, or Viber
+370 675 75 756
