JLG 951042 BRAKE ELECTRIC
JLG 951042 Electric Brake , 24V Electromagnetic Motor Brake. JLG 951042 Electric Brake , 24V OEM electromagnetic brake.
83.5 mm coil diameter, dual friction plates, adjustable air gap, integrated plug connection, and 10 mm internal coupling. Designed for JLG electric scissor lifts and compact R series platforms.
External Ø coil D1:83.5 mm
Internal Ø coil D3:22 mm
Center distance C:62.5 mm
Voltage coil 1 U1:24 V
Lever YES/NO LEV: NO
Number of wires AT-DR:2
Plug YES/NO FIC: YES
Regulation ring couple RING: NO
Micro switch YES/NO MCR: NO
Adjustable air gap YES/NO LU-SP: YES
Fixation bolts YES/NO BV-BO: YES
Number of friction plates AT-PL:2
Dust cover YES/NO ST-AF: NO
Number of brake discs AT-RS:1
Material of brake disc MAT-RS:plastic
Coupling YES/NON MNM: YES
Maximal internal Ø coupling D5:10 mm
Compatible JLG Models
The JLG 951042 Electric Brake is typically installed in various JLG electric scissor lifts and compact access platforms, including:
JLG 1230ES
JLG 1932R
JLG 2032R
JLG 2632R
Important: Model compatibility may vary by serial number and production year. Always verify part number 951042 and dimensions before ordering.
Contact us with your machine serial number if confirmation is required.
ORDER ONLINE: https://machinerypartsonline.eu/product/jlg-951042-electric-brake-24v
