Type of pump group TY-PG
motor-pump-reservoir
Length L1 (mm):485
Width B1 (mm):290
Height H1 (mm):190
AC / DC:direct current
Minimum voltage U1 (V):12
Power (kW):1.6
Cooling fan present:NO
Continuous operation:NO
Starter relay present:YES
Tension starter relay U3 (V):12
Pressure (Bar):60
Capacity (cc/rev):3.2
Type of flange:without flange
Number of pump elements:1
Direction of rotation hydraulic pump:clockwise
Thread type TA1:1/4 BSP
Capacity reservoir (L):5
Length reservoir L2 (mm):260
Width reservoir B2 (mm):170
Height reservoir H2 (mm):170
Position:horizontal
Decompression:electrical
Tension of the valve U4 (V):12
www.machinerypartsonline.eu
www.machinerypartsonline.com.au
JLG 1001277869 MOTOR
Type of pump group TY-PG
motor-pump-reservoir
Length L1 (mm):485
Width B1 (mm):290
Height H1 (mm):190
AC / DC:direct current
Minimum voltage U1 (V):12
Power (kW):1.6
Cooling fan present:NO
Continuous operation:NO
Starter relay present:YES
Tension starter relay U3 (V):12
Pressure (Bar):60
Capacity (cc/rev):3.2
Type of flange:without flange
Number of pump elements:1
Direction of rotation hydraulic pump:clockwise
Thread type TA1:1/4 BSP
Capacity reservoir (L):5
Length reservoir L2 (mm):260
Width reservoir B2 (mm):170
Height reservoir H2 (mm):170
Position:horizontal
Decompression:electrical
Tension of the valve U4 (V):12
