The HYDAC 3000489 is a genuine OEM 12V DC solenoid coil designed for HYDAC hydraulic cartridge valves. Identified by the model code Coil 12DG-40-1836 QS, it features a DIN EN 175301-803 connector, 18W power rating, and continuous-duty operation. This heavy-duty coil is engineered for reliable valve actuation in demanding mobile and industrial hydraulic applications.
Product Details:
Part Number: 3000489
Description: Hydraulic Solenoid Coil
Model Code: Coil 12DG-40-1836 QS
Manufacturer: HYDAC
Operating Voltage: 12V DC
Power Rating: 18W
Electrical Connection: DIN EN 175301-803 (DIN connector)
Function: Energizes HYDAC hydraulic cartridge valves for precise control of hydraulic flow and pressure.
Technical Specifications:
Operating Voltage: 12V DC
Power Consumption: 18W
Resistance (20°C): 8 Ω
Nominal Current: 1.5 A
Coil Height: 40 mm
Protection Rating: IP65
Duty Cycle: Continuous (85%–115% of nominal voltage)
Maximum Coil Temperature: 160°C
Encapsulation: Black polyamide
Connector Type: DIN EN 175301-803
Condition: New
Shipping: Fast worldwide shipping available
Seller: UAB "Aivenos statybinė technika"
Contact us today via Phone, WhatsApp, or Viber
+370 675 75 756
