SNORKEL 3028795 LIMIT SWITCH.
SNORKEL 3028795 limit switch with top roller plunger actuator, 10mm metal roller, 3A rating, 1NO/1NC contacts and 308mm wire with connector. OEM aerial lift replacement part.
Type of actuator: Roller plunger
Position of the actuator:Top
Position of the roller:Standard
Diameter roller:10 mm
Length of the wire:308 mm
Number of mounting holes:2
Shortest center distance between mounting holes:20.0 mm
Current:3 A
Type of the connection:Wire with connector
Number of limit switches:1
Number of normal open contacts (NO):1
Number of normal closed contacts (NC):1
Material of the roller:Metal
Commonly used on various Snorkel scissor lift models including:
Snorkel S1930
Snorkel S1932
Always verify compatibility using your machine serial number and official parts manual before ordering.
1. What type of actuator does the SNORKEL 3028795 use?
It uses a top-mounted roller plunger actuator with a 10 mm metal roller.
2. What is the current rating?
The switch is rated for 3 Amps.
3. Does this limit switch have both NO and NC contacts?
Yes, it includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact.
4. How is it connected?
It features a 308 mm wire with factory-installed connector.
5. Which machines is it commonly used on?
It is typically installed on Snorkel S1930 and S1932 scissor lift models. Always verify by serial number.
