Type of pump group TY-PG:motor-pump
Length L1:380 mm
Width B1:185 mm
Height H1:155 mm
AC / DC:direct current
Minimum voltage U1:24 V
Power:4.5 kW
Cooling fan present:yes
Direction of rotation motor:clockwise
Starter relay present: no
Type of flange:type A
Number of pump elements:1
Direction of rotation hydraulic pump:counterclockwise
Diameter suction side D1:26.98 mm
Thread type TA1:1 1/16 UNF
Diameter pressure side D2:14.28 mm
Thread type TA2:9/16 UNF
Decompression:without
Lowering choke proportional with pump:no
www.machinerypartsonline.eu
www.machinerypartsonline.com.au
HAULOTTE 4000815820 HYDRAULIC PUMP GROUP
Type of pump group TY-PG:motor-pump
Length L1:380 mm
Width B1:185 mm
Height H1:155 mm
AC / DC:direct current
Minimum voltage U1:24 V
Power:4.5 kW
Cooling fan present:yes
Direction of rotation motor:clockwise
Starter relay present: no
Type of flange:type A
Number of pump elements:1
Direction of rotation hydraulic pump:counterclockwise
Diameter suction side D1:26.98 mm
Thread type TA1:1 1/16 UNF
Diameter pressure side D2:14.28 mm
Thread type TA2:9/16 UNF
Decompression:without
Lowering choke proportional with pump:no
