MANITOU 272376 HYDRAULIC PUMP

Type of pump:gearpump
Number of elements:2
Type of flange:type B
Center distance of mounting holes flange C1 (mm):146
Total length of pump L1 (mm):300
Neck diameter D2 (mm):101.6
Type of shaft:type D
Distance from flange to end L2 (mm):41
Diameter of shaft D3 (mm):21.7
Number of splines:13
Direction of rotation:counterclockwise
Position of suction port 1st element, only for pump type T POS-CO1:side
Type of connections suction port1st element, only for pump type T TY-COa:type C
Thread type of connections suction 1st element:M12
Center distance between mounting holes C-CO1a (mm):35.7
Center distance between mounting holes C-CO2a (mm):69.8
Position of pressure 1st element, only for pump type T POS-CO2:side
Type of connections pressure 1st element, only for pump type T TY-COb:type E
Thread type pressure side of 1st element TA-Pb:M27
Flow control valve present:YES
Biggest Thread type valve TA3:M22
Second Thread type valve TA4:M16
Material of the housing:metal
Weight (kg):30
