Number of connections 1
Type of the connection wire with connector
Number of wires 11
Number of pins 11
Diameter steering column mounting D1 (mm) 45
Total length of the steering column switch L1 (mm) 255
Total width of the steering column switch W1 (mm) 70
Total height of the steering column switch H1 (mm) 110
Length of the cable L2 (mm) 306
Number of mounting holes 2
Diameter of the mounting holes D3 (mm) 5.2
Shortest center distance between mounting holes C1 (mm) 62
Material of the housing metal
Number of levers 1
Forwards present YES
Neutral present YES
Reverse present YES
Neutral Lock present YES
Park present NO
Slow speed present NO
Fast speed present NO
Gear present YES
Number of gears 4
Automatic gear selection present NO
Cruise control present NO
Horn present YES
Left/right direction indicator present NO
Position light present NO
Low beam present NO
High beam present NO
High beam flashing present NO
Master light switch present NO
Automatic light present NO
Fog light present NO
Warning light present NO
Worklight present NO
Revolving/ strobe light present NO
Wiper present NO
Windscreen washer present NO
Fits JCB 531-70, 540 FS PLUS, 550-140, 540, 528 AG, TM300, 4CX444 SUPER, 3CXS-PC, 4CN444 Superm, 4CXSM444.
