The JLG 70002400 Switch is a OEM replacement part engineered for reliable performance and precise control on JLG lift equipment. Built for durability, it ensures smooth, consistent operation and long service life.
Type of pressure switch:switch
Electronical:NO
Total Length L1 (mm):75.2
Largest outer diameter D1 (mm):31.2
Diameter D2 (mm):1
Length thread L2 (mm):7.5
Sort thread:outer thread
Thread size:7/16
Type of thread:UNF
Pitch imperial:20
Right or left handed thread:right-handed
Unit of the thread:imperial
Width across flats inch (fraction):1 1/4
Type of connection:wire with connector
Number of wires with connector:1
Preset pressure BAR (Bar):34.4
Pressure adjustable:NO
Type contact:normally open
